SRA-110-240-CO-RF-SH-N Rotary Actuator
The SRA-110-240-CO-RF-SH-N is the 240-degree variant of the compact SRA-110 class rear-flange (RF) helical rotary actuator, rated at 3000 psi (about 207 bar) and recorded in connection with Putzmeister equipment. On the reference nameplate the 240-degree build carries the factory parts number RA1101K03-0. HM provides technical selection and sourcing / alternative-supply support and confirms the rotation angle, mounting, shaft and ports against your nameplate before quotation; the offered unit is not represented as an original Putzmeister part.
Putzmeister part number
RA1101K03-0
Sourcing / alternative supply for Sungji SRA-110-240-CO-RF-SH-N. Interchangeability confirmed on inquiry.
Specifying a new program? Talk to our engineering team →
Independently sourced / alternative-supply service — not represented as an original Sungji or Putzmeister part. Interchangeability is verified against your unit and drawing before ordering.
At a glance
Quick reference
- Original model
- SRA-110-240-CO-RF-SH-N
- Original brand
- Sungji
- Type
- Rotary actuator
- Rotation
- 240°
- Original part no.
- RA1101K03-0
- Rated pressure
- 3000 psi (207 bar)
- Mounting
- RF rear flange
Confirmed data only
Technical specifications
| Product type | Hydraulic rotary actuator |
|---|---|
| Rotation angle | 240° |
| Cross reference | This is a model-code sourcing entry for the SRA-110 class 240-degree rear-flange unit; the reference nameplate shows factory parts number RA1101K03-0. The 240-degree and 360-degree builds share the same SRA-110 frame but differ in rotation/end-stop geometry and carry different parts numbers (the 360-degree build is RA1101K02-0), so they are not interchangeable; confirm the angle and full suffix against your nameplate. |
| Further data | Torque, pressure, port and mounting dimensions are shared with the engineering drawing on request. |
HM alternative model — confirmed on inquiry. Send us your original model number, part number or machine details and we confirm the matching configuration, specifications and compatibility, then quote. The exact HM model is not published online.
Questions
Frequently asked questions
What does the SRA-110-240-CO-RF-SH-N replace?+
It is the original Sungji model code for a helical hydraulic rotary actuator providing 240° rotation. HM provides sourcing and alternative-supply support for this reference; it is not assumed to be an original Sungji part or a pre-verified interchangeable unit, and the configuration is confirmed against your actuator nameplate and drawing before we quote. It is listed by Putzmeister under part number RA1101K03-0. HM can source or arrange alternative supply for this reference; mounting dimensions, shaft, ports and the exact configuration are checked against your unit and drawing before any alternative is recommended.
What is the difference between SRA-110-240 and SRA-110-360?+
They use the same SRA-110 frame and rear-flange mounting but differ in total rotation: 240 degrees versus 360 degrees, which changes the internal end-stop geometry and the parts number (RA1101K03-0 for the 240-degree build and RA1101K02-0 for the 360-degree build). Read the rotation from your tag; the two units cannot simply be swapped.
Can HM supply the SRA-110-240-CO-RF-SH-N?+
We offer selection and sourcing / alternative-supply support for this 240-degree rear-flange unit. We do not claim a verified drop-in or that the offered unit is an original Putzmeister part; send the nameplate and a mounting drawing and we confirm the angle, mounting, shaft, ports and seal package before quoting.
Why is the exact HM model and price not shown?+
We confirm the HM model per inquiry after verifying the interface and operating parameters with you. This avoids shipping a part that looks right by model name but differs in mounting or rotation. Price is provided with that confirmed quote.
Request sourcing
Need a source for SRA-110-240-CO-RF-SH-N?
Send the original Sungji model number, the Sandvik / OEM part number, machine details or a mounting drawing. We confirm the configuration and advise the available sourcing or alternative-supply option before quoting.
